Automatic Edgebander PCR- 1 Ph- 220V

Automatic Edgebander PCR- 1 Ph- 220V

The Maksiwa CBC.PCR Automatic Edgebander delivers industrial-grade performance with the highly requested corner rounding feature. It also includes pre-milling, trimming, glue scraping, and buffing for a premium finish. The XMELT glue pot system supports EVA and PUR adhesives. With a 8HP motor and user-friendly PCL touchscreen, it handles edge tapes of 0.4-3mm and panel thicknesses from 10-50mm.

Features:
  • Edge Tape: 0.4-3 mm
  • Panel Thickness: 8-50mm
  • 1 Phase 220V 60Hz
  • Corner Rounding Unit
  • Glue Scraper Unit
  • Buffing Unit
  • End Trimming HF Motor
  • Pre-milling Unit 2 HF Motors with Diamond Cutters
  • XMELT Glue Pot System (compatible w/ EVA and PUR Adhesives + easy drainage System)
  • C.A.S.S - Cleaning Agent Spraying System
  • Glue Pot Capacity 1.5kg | 3.3lbs Teflon Coated
  • Automatic feeding Speed 18 ft/min
  • Conveyor Chain Feed System for optimum results.
  • HF motors controlled by independent electronic converters
  • Net Weight 1411 Lbs | 640 kgs
  • Compact Design
  • Melamine/PVC/ABS/PP
Specifications:
  • Automatic Feeding speed: 18 ft/min
  • Panel Thickness Min/Max: 21/64” - 1 31/32”
  • Max Pre-milling Height: 1”
  • Edgebanding Thickness: 0.0157" - 0.118"
  • Glue Pot Capacity: 3.3lbs
  • Max Edgebanding Height: 2"
  • Minimum Panel Width: 3"
  • Minimum Panel Length: 7 7/8"
  • Extendable Panel Support Rail Length: 103"
  • Extension Table Max Width: 54"
  • Size of Dust Collector Ports: 6"
  • Minimum Dust Collection Requirements: 1236 CFM
  • Air Pressure Requirement: 14 SCFM @ 87PSI
  • Edgebanding Coil Support Diameter: 59"
  • Recommend Glue Temperature Range: 356°F - 410°F
  • Max. Machine Dimensions (LxWxH): 119”x 40 16/16”x 48. 7/16”
  • Net Weight: 1411 LBS
  • Shipping Dimensions (LxWxH): 111” x 30” x 57”
  • Glue Type: Granulated Hot-Melt EVA / PUR
  • Electrical Information: 1 Phase, 220V, 60Hz

Shipping / Billing Information

This product ships direct from the manufacturer:

  • Your order will ship in approximately 5-7 business days.
  • This product is considered special order. Your account will be charged when you place your order.
  • Express or overnight shipping is not available for this product.
  • Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.

Any suspected damage must be reported on bill of lading for all freight items

Return Information

If you have a return issue, contact Woodcraft Supply customer service @ 1-800-535-4482 for return details. All Returns must have a RGA or will be refused. Customer is responsible for all return freight.

Warranty Information

Maksiwa warranty's Power Tools for 2 years. If you have a warranty question, please contact Maksiwa Customer Service at 754/2276096
$12,915.00

Original: $36,900.00

-65%
Automatic Edgebander PCR- 1 Ph- 220V—

$36,900.00

$12,915.00
