Compact Table Saw

Compact Table Saw

SawStop’s smallest, most portable saw yet – with everything you’ve come to expect from a SawStop. This Compact Table Saw is packed with features that bring power, precision, cut capacity, and safety to every job site. The table saw’s unique brake design detects hand or finger contact with the saw blade within milliseconds, instantly stopping and retracting the blade, helping to avoid serious injury. In addition to the groundbreaking safety features, SawStop manufactures one of the most precise saws on the market. The fit, finish and tolerance levels are second to none. The rack and pinion fence is easy to adjust and always square, and the built-in high and low shelf supports all kinds of cuts. All blade adjustments are made from the centrally located knob, which allows for quick and easy tilting of the blade to your ideal angle with just one hand. Dial in your precise settings with the micro-adjust feature. This Compact Table Saw only uses TSBC-10R3 brake cartridge.

Features:

  • Lightweight and portable
  • Easy to adjust rack and pinion fence
  • One-handed blade adjustments
  • Rigid tube structure and rubber feet provide a durable, stable cutting experience
  • SawStop Safety System stops on contact with skin

Specifications:

  • Motor: 120 VAC 60 HZ, Universal
  • Amperage: 15A
  • No Load RPM: 4,000
  • Blade Diameter: 10"
  • Max. Depth of Cut at 0°: 3-1/8"
  • Max. Depth of Cut at 45°: 2-1/8"
  • Max. Rip Capacity: 24-1/2"
  • Dimensions: 23-1/2" W x 27" L x 14-1/4" H
  • Table Surface: 23" W x 22-5/8" D
  • Weight: 68 pounds

What’s Included:

  • (1) SawStop Compact Table Saw
  • (1) Miter Gauge
  • (1) Brake Cartridge (installed)
  • (1) 3 mm Hex Key
  • (2) Blade Wrenches
  • (1) Riving Knife (installed)
  • (1) Blade Guard with Spreader and Anti-Kickback Pawls
  • (1) 24-Tooth Ripping Blade (installed)
  • (1) Pushstick (on fence)
  • (1) Table Saw Insert (installed)

Notes:

  • THIS SAW WILL NOT ACCEPT A DADO BLADE.

FAQs

How to use a table saw?
Adjust the blade height and fence position, then feed your workpiece steadily and firmly through the blade. Always use a push stick for narrow cuts and wear safety glasses and hearing protection.


How to change a table saw blade?
Unplug the saw, remove the throat plate, and use the arbor wrench to loosen the arbor nut. Replace the blade, making sure it’s seated correctly, and tighten the nut before reassembling the throat plate.


$899.00
Compact Table Saw—
$899.00

Product Information

Shipping & Returns

Description

SawStop’s smallest, most portable saw yet – with everything you’ve come to expect from a SawStop. This Compact Table Saw is packed with features that bring power, precision, cut capacity, and safety to every job site. The table saw’s unique brake design detects hand or finger contact with the saw blade within milliseconds, instantly stopping and retracting the blade, helping to avoid serious injury. In addition to the groundbreaking safety features, SawStop manufactures one of the most precise saws on the market. The fit, finish and tolerance levels are second to none. The rack and pinion fence is easy to adjust and always square, and the built-in high and low shelf supports all kinds of cuts. All blade adjustments are made from the centrally located knob, which allows for quick and easy tilting of the blade to your ideal angle with just one hand. Dial in your precise settings with the micro-adjust feature. This Compact Table Saw only uses TSBC-10R3 brake cartridge.

Features:

  • Lightweight and portable
  • Easy to adjust rack and pinion fence
  • One-handed blade adjustments
  • Rigid tube structure and rubber feet provide a durable, stable cutting experience
  • SawStop Safety System stops on contact with skin

Specifications:

  • Motor: 120 VAC 60 HZ, Universal
  • Amperage: 15A
  • No Load RPM: 4,000
  • Blade Diameter: 10"
  • Max. Depth of Cut at 0°: 3-1/8"
  • Max. Depth of Cut at 45°: 2-1/8"
  • Max. Rip Capacity: 24-1/2"
  • Dimensions: 23-1/2" W x 27" L x 14-1/4" H
  • Table Surface: 23" W x 22-5/8" D
  • Weight: 68 pounds

What’s Included:

  • (1) SawStop Compact Table Saw
  • (1) Miter Gauge
  • (1) Brake Cartridge (installed)
  • (1) 3 mm Hex Key
  • (2) Blade Wrenches
  • (1) Riving Knife (installed)
  • (1) Blade Guard with Spreader and Anti-Kickback Pawls
  • (1) 24-Tooth Ripping Blade (installed)
  • (1) Pushstick (on fence)
  • (1) Table Saw Insert (installed)

Notes:

  • THIS SAW WILL NOT ACCEPT A DADO BLADE.

FAQs

How to use a table saw?
Adjust the blade height and fence position, then feed your workpiece steadily and firmly through the blade. Always use a push stick for narrow cuts and wear safety glasses and hearing protection.


How to change a table saw blade?
Unplug the saw, remove the throat plate, and use the arbor wrench to loosen the arbor nut. Replace the blade, making sure it’s seated correctly, and tighten the nut before reassembling the throat plate.
